The days are long past when a fast office Wi-Fi connection was a nice-to-have. These days it's essential for your business to provide clients and employees alike with a speedy, reliable wireless network.
Proper site surveying and maintenance are crucial for wireless networks, and especially so for networks with heavy traffic, such as Wi-Fi hotspots at public venues. The same is true when speed is vital, as when streaming video or voice over Wi-Fi.
Interference, congestion, improper security settings and lack of maintenance are just a few factors that can negatively affect Wi-Fi performance. Fortunately, there are several techniques you can use to combat these issues.
But before I go into specifics, a bit of background. Wi-Fi is all about airtime: the amount of time a wireless device or access point (AP) is transmitting. Airtime is important because usually only one device can transmit at a time on a given channel. The wireless devices and APs have to share the airwaves and take turns talking. The slower the transmission speed, the more airtime a device takes up and the less time available for other devices.
True, multiuser MIMO now makes it possible for an AP to simultaneously transmit to multiple wireless devices on the same channel. However, this technology is just emerging, and it will take some time before many devices support it, especially business and enterprise-class APs.
Note that if your workplace has areas that are lacking Wi-Fi coverage altogether, adding or moving existing wireless APs around is likely the best place to start. However, if there aren't major holes in coverage and the chief concern is slow speeds, I suggest using the techniques in this story before moving or adding APs.
If your network has a wireless controller or your APs have built-in controller functionality, then you can tweak the settings I discuss from a central interface. Otherwise you'll likely have to log in to each AP to make the recommended changes.
1. Minimize interference
One of the first things to do when optimizing Wi-Fi is to reduce or eliminate interference. Unlike working with cables in wired networks, you can't easily control Wi-Fi's transport medium: the airwaves. There will likely be some type of interference you must contend with, whether from other nearby Wi-Fi networks, co-channel interference from your own network, or non-Wi-Fi signals in the same radio spectrum.
The Wifi Analyzer stumbler app for Android clearly shows co-channel interference.
Start with what is most controllable: co-channel interference, which is the interference caused by having two or more Wi-Fi access points on the same or overlapping channels. Though most APs have an auto channel function that is supposed to pick the best channel, I suggest double-checking their selections.
Co-channel interference is a bigger problem in the 2.4GHz band than in the 5GHz band. There are 11 channels in the 2.4GHz band, but only three channels don't overlap: 1, 6 and 11. In the 5GHz band, there are up to 24 channels, and they don't overlap if the legacy 20MHz channel widths are used. Though some APs don't support all the channels and larger channel widths cause some overlapping, the 5GHz band is still bigger.
When checking channels on smaller networks, such as those with six or fewer APs, you could use a free Wi-Fi stumbler on a laptop or Android device. These simple apps scan the airwaves and list the basic details about nearby wireless routers and APs, including channel usage.
For larger networks, consider using a map-based Wi-Fi surveying tool (such as those from AirMagnet, Ekahau or TamoGraph) during deployment and for periodic checks. Along with capturing Wi-Fi signals, these tools enable you to run a full RF spectrum scan to look for non-Wi-Fi interference as well.
Ekahau Site Survey and similar tools can show a heatmap of co-channel interference.
For ongoing interference monitoring, use any functionality built into the APs that will alert you to rogue APs and/or other interference.
Map-based Wi-Fi surveying solutions usually offer some automated channel analysis and planning features. However, if you're doing a survey on a smaller network with a simple Wi-Fi stumbler, you'll have to manually create a channel plan. You might want to start assigning channels to APs on the outer edges of your coverage area first, as you'll have to deal with neighboring wireless networks. Then work your way into the middle, where you're more likely to have to deal with only your own APs.
2. Use 5GHz and band steering
As mentioned, the 5GHz band offers many more channels than 2.4GHz; thus, I strongly encourage having dual-band APs that support 5GHz as well. This allows older Wi-Fi devices to connect in the lower band and newer dual-band devices to connect via the higher band. Less congestion in the lower band generally means faster connections, and devices in the higher band typically support higher data rates, both of which help to decrease the airtime of devices. Although not all new Wi-Fi devices are dual-band, more and more are these days, especially the higher-end smartphones and tablets.
In addition to supporting 5GHz, consider using any band-steering functionality provided by the APs. This can encourage or force dual-band devices to connect to the higher band instead of leaving it up to the device or user.
Many APs only allow you to enable or disable band steering, while some also allow you to configure signal thresholds, so dual-band devices that would have a stronger signal on 2.4GHz aren't forced to use 5GHz. This is helpful because 5GHz offers a shorter range than the lower band. If your AP supports it, I suggest using the signal threshold setting — it provides a good compromise between reducing congestion on 2.4GHz while offering users the best signal.
Even if your AP doesn't allow you to configure signal thresholds (like the one pictured here), it may have a default threshold set.
3. Use only WPA2 security
It's not a secret that WEP security is insecure, even though virtually all APs still support it. Thus, it's important to use either WPA or WPA2. However, when using the first version of WPA, the data rates on the wireless network are limited to 54Mbps, the maximum rate of the old 802.11a and 802.11g standards.
To ensure you can take advantage of the higher data rates offered by 802.11n (up to 450Mbps) and 802.11ac (currently up to 1.3Gbps), use only WPA2 security with AES encryption. Unless you specifically choose WPA2 only, many APs will default to supporting both versions. Since virtually all wireless devices these days support both versions, you should just force the use of the second.
4. Reduce the number of SSIDs
If you have more than one SSID configured on the APs, keep in mind that each virtual wireless network must broadcast separate beacons and management packets. This consumes more airtime, so use multiple SSIDs sparingly. One private SSID and one public SSID is certainly acceptable, but I'd stay away from using virtual SSIDs to do things like segregate wireless access by departments.
If network segregation is needed, consider using 802.1X authentication to dynamically assign users to VLANs upon connecting to the SSID. This way you can have just one private SSID, but at the same time virtually segregate the wireless traffic.
5. Don't hide SSIDs
You may have heard that hiding a network name by disabling the SSID in the beacon broadcasting can help with security. However, it only hides the network name from casual users; most devices will show that there's an unnamed network nearby. Additionally, anyone with a Wi-Fi analyzer can usually discover the SSID, since it will still be present in some management traffic.
This wireless network analyzer showed the hidden SSID of 'cottage111' after I connected a device to the network.
Hiding an SSID also causes extra management traffic on the network, such as probe requests and responses, which take up more airtime. Furthermore, hidden SSIDs can be confusing and time consuming for users since they have to manually enter the network name when connecting to the Wi-Fi. Thus, this approach to security can actually do more damage than good.
A more beneficial security technique is to use the enterprise mode of WPA2. If you find the enterprise mode is too hard to set up or that not all devices on the network support it, be sure to have a long and strong passphrase with mixed case and characters. Also consider changing the passphrase periodically and after any user leaves the organization or loses a Wi-Fi device.
